Single Axle Outside Rail Hoist




Single Axle Outside Rail Hoist

Single axle hoists are designed to carry smaller containers. Shorter wheelbases allow for tighter turning and access to confined spaces. The Outside Rail is the most popular in the industry today.

  • Short wheel base enables it to fit in tight areas
  • 50 degree dump angle
  • Fast cycle time keeps drivers on the road

Single Axle Outside Rail Hoist

Our Advantage

Outboard Supported Lift Brackets

Lift brackets increase stability when hoist is in the up position.

Rigid DOT/ICC Bumper

Durable bumper constructed from square tubing.

Outboard Supported Side Rollers

Greasable shaft is removable with two bolts.

Outside Control Valve

Controls are easy access and makes maintenance very accessible.

Features
  • 8 x 4 x 3/8” Tube Main Frame
  • 4 x 3 x 3/16” Tube Sub Frame
  • All Working Points Greasable
  • 1” Spring Loaded Container Stops
  • 2 1/2” diameter Lift Shaft
  • 10” diameter Cable Sheaves
  • Sealed Lighting System
  • Hydraulic Reservoir
  • Hoist Up Alarm
  • Back Up Alarm
  • 5/8” Cable
Options

For the Ultimate in Container Securement, add “The Hooker” to your Roll Off Hoist.

The Single Axle Outside Rail Hoist can be paired with these Chassis and Containers



Product Specifications

* Cycle Times are Factory developed and controlled by PTO output, oil viscosity, human and mechanical efficiency, and may vary accordingly. All dimensions are subject to steel and manufacturing tolerances.

Videos

Rollers are bolted to the side of the frame, allowing for easier replacement and better support of the container.
